- General Information
- Manufacturer
- Lenovo Group Limited
- Manufacturer Website Address
- http://www3.lenovo.com/au/en
- Brand Name
- Lenovo
- Product Line
- ThinkSystem
- Product Series
- ST650 V3
- Product Type
- Server
The Lenovo ThinkSystem ST650 V3 is an ideal 2-socket 4U tower server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The ST650 V3 is based on the new 4th generation Intel Xeon Scalable processor family.
The ST650 V3 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.
- Warranty
- Limited Warranty
- 3 Year
- Additional Warranty Information
Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD).
- Processor
- Number of Processors Supported
- 2
- Number of Processors Installed
- 1
- Processor Manufacturer
- Intel
- Processor Type
- Xeon Silver
- Processor Generation
- 4th Gen
- Processor Model
- 4410Y
- Processor Core
- Dodeca-core (12 Core)
- Processor Speed
- 2 GHz
- Cache
- 30 MB
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- C741
- Memory
- Standard Memory
- 16 GB
- Maximum Memory Supported
- 4 TB
- Memory Technology
- TruDDR5
- Memory Clock Speed
- 4.80 GHz
- Error Checking
- ECC
- Total Number of Memory Slots
- 32.0
- Number of Occupied Memory Slots
- 1
- Signal Processing
- Registered (Buffered)
- Controllers
- Controller Type
- Serial ATA
- 12Gb/s SAS
- Controller Model
- 9350-16i
- RAID Supported
- Yes
- I/O Expansions
- Number of Total Expansion Bays
- 8
- Number of 3.5" Bays
- 8
- Number of LFF Bays
- 8
- Hot Swappable Bays
- Yes
- Total Number of Expansion Slots
- 9.0
- PCI Express Details
- Up to nine PCIe slots, five of which are PCIe 5.0.
- Display & Graphics
- Graphics Memory Capacity
- 16 MB
- Network & Communication
- Ethernet Technology
- 10 Gigabit Ethernet
- Interfaces/Ports
- Total Number of USB Ports
- 8
- Number of USB 2.0 Ports
- 1
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 2
- VGA
- Yes
- Number of VGA Ports
- 1
- Remote Management
- Yes
- Remote Management Controller
- XCC Standard
- Operating System
- Operating System Supported
- Red Hat Enterprise Linux 8.7
- Red Hat Enterprise Linux 9.0
- Red Hat Enterprise Linux 9.1
- SUSE Linux Enterprise Server 15 SP4
- Ubuntu 22.04 LTS x64
- Windows Server 2022
- Red Hat Enterprise Linux 8.6
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Number of Power Supplies Supported
- 2
- Number of Power Supplies Installed
- 1
- Plug/Connector Type
- C13/C14
- Maximum Power Supply Wattage
- 750 W
- Hot Swappable Power Supply
- Yes
- Power Source
- Power Supply
- Physical Characteristics
- Form Factor
- Tower
- Rack Height
- 4U
- Height
- 462 mm
- Width
- 175 mm
- Depth
- 734 mm
- Weight (Approximate)
- 39.10 kg
- Miscellaneous
- Package Contents
- ThinkSystem ST650 V3 7D7AA01SAU Server
- Power Cord
- Security Features
- Administrator and Power-on Password
- Trusted Platform Module (TPM)
- Self-encrypting drives (SEDs) with support for enterprise key managers
- Energy Star
- Yes
- Environmentally Friendly
- Yes
- Energy Efficiency Certification
- China Energy Conservation Program (CECP)
