The Moxa EDS-P506E-4PoE-2GTXSFP-T is a high-performance Gigabit managed PoE+ Ethernet switch designed for mission-critical applications in harsh industrial environments. It comes equipped with four 10/100BaseT(X) Ethernet ports that comply with IEEE 802.3af (PoE) and 802.3at (PoE+) standards. These ports can deliver up to an impressive 60W of power each, making them ideal for power-hungry devices such as weatherproof IP cameras with heaters, high-performance wireless access points, and rugged IP phones.
Engineered for versatility and resilience, the switch includes two Gigabit combo ports that can be used for high-bandwidth copper or SFP fibre optic uplinks, enabling long-distance data transmission with high immunity to electromagnetic interference. The EDS-P506E-4PoE-2GTXSFP-T is built to withstand extreme conditions, featuring a wide operating temperature range of -40 to 75°C and 4kV surge protection to ensure the continuous reliability of your PoE systems.
This switch offers a comprehensive suite of management functions to ensure network uptime and security. It supports advanced redundancy protocols like STP/RSTP, Turbo Ring, and Turbo Chain for rapid network recovery. Additionally, it integrates seamlessly into industrial control systems with support for EtherNet/IP, PROFINET, and Modbus TCP protocols. Smart PoE functions such as device auto-checking, power scheduling, and diagnostics allow for proactive management and troubleshooting of connected powered devices.
FEATURES
- 4 IEEE 802.3af/at compliant PoE+ ports
- Up to 60W power output per PoE port
- 2 Gigabit combo ports for flexible copper or fibre uplinks
- Wide operating temperature range from -40 to 75°C
- Supports EtherNet/IP, PROFINET, and Modbus TCP for industrial integration
- Smart PoE functions for remote diagnosis and failure recovery
- Turbo Ring and Turbo Chain for fast network redundancy (<20ms recovery)
- 4kV surge protection for enhanced system reliability
- Supports MXstudio for easy, visualised industrial network management
SPECIFICATIONS
- PoE Ports: 4 x 10/100BaseT(X) RJ45
- Combo Ports: 2 x 10/100/1000BaseT(X) or 100/1000BaseSFP+
- PoE Standards: IEEE 802.3af/at
- Max. PoE Power Output per Port: 60W
- Total PoE Power Budget: 180W @ 48VDC input
- Input Voltage: 12/24/48VDC (Redundant dual inputs)
- Operating Temperature: -40 to 75°C (-40 to 167°F)
- Housing: Metal
- IP Rating: IP40
- Dimensions: 49.1mm x 135mm x 116mm
- Installation: DIN-rail mounting, Wall mounting (with optional kit)
- Redundancy Protocols: STP, RSTP, MSTP, Turbo Ring v1/v2, Turbo Chain
- Industrial Protocols: EtherNet/IP, PROFINET, Modbus TCP
- Security: HTTPS/SSL, SSH, RADIUS, TACACS+, MAC ACL, Port Lock
- Management: SNMPv1/v2c/v3, CLI, Web Console, RMON
WARRANTY
5-Year Limited Warranty
