The Moxa EDS-510E-3GTXSFP is a robust Gigabit managed Ethernet switch engineered for demanding, mission-critical industrial applications like factory automation, intelligent transportation systems (ITS), and process control. [cite: 14] It provides a reliable networking solution designed for operational stability and resilience in harsh environments. With its versatile port configuration, including seven 10/100BaseT(X) ports and three Gigabit combo ports, this switch offers exceptional flexibility for network design and expansion. [cite: 45, 55]
Network reliability is paramount in industrial settings, and the EDS-510E-3GTXSFP delivers with advanced redundancy features. It supports Moxa's Turbo Ring and Turbo Chain technologies, ensuring network recovery in less than 50 milliseconds for up to 250 switches. Additionally, it is compatible with standard protocols like RSTP/STP and MSTP, providing multiple layers of network resilience to prevent downtime and maintain continuous operations.
Enhanced security and management capabilities are central to the EDS-510E-3GTXSFP's design. The switch incorporates features such as RADIUS, TACACS+, IEEE 802.1x, and SSH to safeguard your network against unauthorised access. For seamless integration and device monitoring within industrial control systems, it supports EtherNet/IP, PROFINET, and Modbus TCP protocols. Configuration is simplified through various interfaces including a web browser, CLI, and a USB port for system file backup and firmware upgrades. [cite: 16, 22]
Built to withstand tough conditions, the EDS-510E-3GTXSFP features a durable metal housing with an IP30 rating and supports DIN-rail mounting for easy installation. [cite: 115, 120] It operates reliably in temperatures ranging from -10 to 60°C and is certified for use in hazardous locations and power substations. [cite: 120] The inclusion of redundant dual power inputs further enhances its dependability, making it an ideal choice for critical infrastructure where network availability cannot be compromised. [cite: 115]
FEATURES
- 7 x 10/100BaseT(X) RJ45 ports and 3 x Gigabit combo ports [cite: 45, 55]
- Supports Turbo Ring and Turbo Chain for fast network recovery (<50 ms)
- Advanced network security with RADIUS, TACACS+, SNMPv3, and IEEE 802.1x
- Industrial protocol support including EtherNet/IP, PROFINET, and Modbus TCP
- Multiple management options: web browser, CLI, Telnet/USB console [cite: 18, 22]
- Redundant dual power inputs (12/24/48/-48 VDC) [cite: 115]
- USB interface for configuration, firmware upgrades, and file backup
- IP30 rated metal housing with DIN-rail mounting capability [cite: 115, 120]
SPECIFICATIONS
- MAC Table Size: 8K
- Packet Buffer Size: 1Mbits
- Max. No. of VLANs: 64
- VLAN ID Range: 1 to 4094
- Input Voltage: 12/24/48/-48 VDC (9.6 to 60VDC) [cite: 115]
- Input Current: 0.68A @ 24VDC [cite: 115]
- Power Connection: 2 x removable 4-contact terminal blocks [cite: 115]
- Housing: Metal [cite: 115]
- IP Rating: IP30 [cite: 115]
- Dimensions: 79.2mm x 135mm x 116mm [cite: 115]
- Weight: 1263g [cite: 120]
- Installation: DIN-rail or Wall mounting (kit optional) [cite: 120]
- Operating Temperature: -10 to 60°C [cite: 120]
- MTBF: 725,532 hrs [cite: 120]
WARRANTY
5-Year Limited Warranty
...
