- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com.au
- Brand Name
- APC by Schneider Electric
- Product Line
- Easy UPS On-Line
- Packaged Quantity
- 1 Pack
- Product Type
- Double Conversion Online UPS
- Warranty
- Limited Warranty
- 2 Year
- Additional Warranty Information
2 years repair or replace
- Technical Information
- Plug/Connector Type
- Hard Wire 3-wire (1P + N + E)
- Hard Wire 5-wire (3P + N + E)
- Receptacle Type
- Hard Wire 3-wire (1P + N + E)
- Receptacle Detail
- 1 x Hard Wire 3-wire (1P + N + E)
- Efficiency
- 95.1%
- Power Description
- Load Capacity (VA)
- 20 kVA
- Load Capacity (Watt)
- 20 kW
- Input Voltage
- 230 V AC
- 415 V AC
- 120 V AC
- Input Voltage Range
- 110 V AC - 300 V AC
- 176 V AC - 300 V AC
- Output Voltage
- 230 V AC
- 220 V AC
- 240 V AC
- Input Frequency
- 40 Hz
- 70 Hz
- Output Frequency
- 50 Hz
- 60 Hz
- Waveform Type
- Sine Wave
- Surge Energy Rating
- 600 J
- Display & Graphics
- Display
- LCD
- Management
- Network Management
- Intelligent Card Slot
- SmartSlot
- RS-232
- Alarm
- On Battery
- Low Battery
- Overload
- Interfaces/Ports
- Serial Port
- Yes
- USB
- Yes
- EPO Port
- Yes
- Battery Information
- Battery Characteristics
- Valve-regulated
- Battery Chemistry
- Lead Acid
- Backup/Run Time (Full Load)
- 2.02 Minute
- Backup/Run Time (Half Load)
- 9.37 Minute
- Typical Battery Recharge Time
- 6 Hour
- Environmental Conditions
- Maximum Operating Temperature
- 40°C
- Maximum Operating Elevation
- 3 km
- Maximum Storage Elevation
- 15 km
- Storage Relative Humidity
- 0% - 95%
- Sound Emission (A-Weighted)
- 65 dB(A)
- Thermal Dissipation
- 3712 BTU/h
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Form Factor
- Rack-mountable
- Rack Height
- 9U
- Mounting Location
- Front
- Height
- 393 mm
- Width
- 438 mm
- Depth
- 690 mm
- Weight (Approximate)
- 157 kg
- Miscellaneous
- Package Contents
- Easy UPS On-Line 20000VA Rack-mountable UPS
- 1 x USB Cable
- 1 x RS-232 Configuration Cable
- 3 x Rack Mounting Brackets
- 3 x Stabilization/wall Mounting Feet
- 6 x Jumper Bar
- 2 x External Battery Pack
- 1 x Battery Cable
- User Manual
- Certifications & Standards
- CE
- UKCA
- EN/IEC 62040-1:2019/A11:2021
- EN/IEC 62040-2:2006/AC:2006
- EN/IEC 62040-2:2018
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- China Restriction of Hazardous Substances (China RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
